Full Width Belt
The Full Width Belt Sorter provides reliable sortation of cartons, totes and trays up to 70 cpm. The sorter is designed with a belted transportation surface and multiple 30° wheeled divert mechanisms that avoid tilting cartons, allowing boxes or trays with open tops to be handled.
Full Width Belt Overview
-
Reliable Throughput: Capable of sorting up to 70 cartons per minute.
-
Gentle Handling: Belted transportation surface ensures stability and reduces product damage.
-
Precise Diverting: 30° wheeled divert mechanisms avoid tilting, making it perfect for open-top boxes and trays.
-
Versatile Application: Suitable for various items such as cartons, totes and trays.
Up to 120' or 12 sortation locations
-
Currently available at 24", 27" and 30" BF
-
Available above 24" TOB
-
Left or Right Diverts at 30º
-
Multiple sorters can be installed end-to-end to achieve a longer sortation line
Up to 70 CPM Sortation (16" average carton)
-
Carton, Totes and Trays
-
9" x 6" minimum carton size
-
30" minimum gap
-
Up to 300 fpm
-
Maximum 25lbs/ft or 60lb product
Specifications
-
Speed: 150–300 FPM
-
Low noise at the highest throughput
-
Precise control trajectories
-
Modular design – minimal
spare parts
-
Proven technology for medium
to high throughput -
3 to 5 horsepower drive motor helps provide longer and faster belts
